Product Overview
The Heavy-Duty Multi-Cylinder Hydraulic Press Brake is engineered for industrial-grade, long-span sheet metal bending and profile forming. Built with an ultra-rigid welded structural steel portal frame and driven by a three-cylinder synchronized hydraulic system, this machine guarantees exceptional stability, high pressing force, and consistent bend angles across extended sheet lengths.
Whether you are manufacturing roofing and wall cladding, architectural flashings, door frames, HVAC ducting, or structural metal enclosures, this press brake offers the perfect balance of robust power, precision angle control, and cost-effective productivity.
Key Features & Highlights
-
⚙️ Tri-Cylinder Synchronized Drive System
Equipped with three heavy-duty hydraulic cylinders evenly distributed along the upper beam. This multi-point loading design prevents mid-span deflection, ensuring uniform bending force and straight, accurate angles across extra-long workpieces.
-
🏗️ Ultra-Rigid Steel Portal Frame Construction
Built from high-tensile, heavy-duty welded structural steel I-beams and channel sections. The stress-relieved frame resists distortion under full tonnage, delivering long-term structural integrity and steady performance under heavy working cycles.
-
✂️ Segmented Precision Tooling System
Features modular upper punch segments clamped securely along the beam and a multi-V bottom die bed. The segmented design allows quick tool positioning, easy replacement, and flexibility for complex box, pan, or profile bending.
-
🕹️ Ergonomic Control & Foot Switch Operation
Integrated side-mounted electrical control cabinet allows simple power and stroke management. Paired with a heavy-duty floor foot pedal, operators can execute hands-free, safe, and precise bending sequences.
-
📏 Extended Bending Length Capacity
Designed specifically for processing extra-wide and long sheet metal panels (e.g., 4,000 mm to 6,000 mm+ working bed length), eliminating the need for repositioning and dramatically reducing labor time.
-
💧 Reliable High-Pressure Hydraulic Circuit
Engineered with high-grade flexible hydraulic lines, industrial valves, and chrome-plated cylinder piston rods for smooth stroke control, rapid response, and minimal maintenance downtime.
Technical Specifications
| Parameter / Item | Specification / Capability |
| Applicable Materials | Galvanized Steel, Cold-Rolled Steel, Aluminum Alloy, Stainless Steel |
| Material Thickness Range | 0.3 mm – 3.0 mm (Customizable up to 5.0 mm) |
| Effective Processing Width | 1,000 mm / 1,250 mm / 1,500 mm (Tailored to customer needs) |
| Pattern Types | Diamond Tread, 5-Bar Checker Plate, Teardrop, Stucco, Custom Logos |
| Roller Material & Hardness | Forged Alloy Steel 42CrMo / 60CrMoV (HRC 58 – 62) |
| Working Speed | 0 – 22 m/min (Frequency Inverter Speed Control) |
| Leveling Unit | Multi-roller precision flattening system (11–13 leveling shafts) |
| Slitting & Cutting Unit | Adjustable rotary slitting knives + Hydraulic cut-to-length shear |
| Control System | Delta PLC + Touchscreen HMI |
| Main Motor Power | 15.0 kW – 22.0 kW (Depending on sheet thickness) |
| Total Weight | Approx. 7.5 – 9.5 Tons |
Typical Applications
-
🏠 Roofing & Building Cladding: Long metal roof tiles, ridge caps, wall panels, and gutter flashings.
-
🚪 Door & Frame Manufacturing: Steel security door frames, metal door panels, and jamb profiles.
-
🏛️ Architectural Metalwork: Decorative facades, aluminum composite trims, and custom metal trim channels.
-
❄️ HVAC & Enclosures: Industrial air ducting, generator housings, and electrical cabinet panels.
-
🚚 Commercial Vehicles: Trailer side walls, truck bed cross-members, and chassis channel sections.
. Customization & OEM Support
-
Custom Pattern Design: We offer custom engraved pattern designs including corporate logos, decorative textures, and specialized anti-slip designs.
-
Turnkey Solutions: Inline uncoiler, slitting, embossing, shearing, and stacking solutions available based on factory layout.
-
Global Technical Support: online video guide, and life aftersale service
Ready to Upgrade Your Sheet Metal Processing Line?
Contact our engineering team today to receive a customized technical drawing, full machinery proposal, and competitive quote!
